Matrice 300 RTK

Highlights:

• 55 minute MAX flight time (no payload) - RMUS technicians clocked MAX time at 38 minutes with H20T payload
• Handoff - One pilot can "handoff" drone to another pilot to help keep drone within line of sight
• Battery Hotswap - Drone does not power down when changing out batteries, which improves turn around time between missions.
• IP45 Rated - Able to fly in light rain
• Self-Heating Batteries
• Operating Temperature Range from -4°F to 156°F
• Airsense ADS-B Receiver
• Smart Pin & Track - Advanced tracking of moving objects and the pin point of their geo-location
• RTK compatible with existing D-RTK 2 Basestation for Phantom 4 RTK or M210 RTK
• 9 mile Max Transmission
• Smart Inspection with drone position and camera settings saved to get repeat imagery for routine inspections.
• 6 direction sensing and positioning

A new standard for the commercial drone industry

The Matrice 300 RTK takes inspiration from modern aviation systems. Offering up to 55 minutes of flight time, advanced AI capabilities, 6 Directional Sensing & Positioning, and more, the M300 RTK sets a whole new standard by combining intelligence with high-performance and unrivaled reliability.

Features:

• 9.3 miles max transmission range
• 55 minute max flight time
• 6 directional Sensing and Positioning
• Redesigned primary flight display
• IP45 water and dust protection
• -4°F to 122°F Operating temperature
• Hot-swappable battery
• UAV Health Management System

Improved transmission system

The all-new OcuSync Enterprise enables transmission up to 15 km away and supports triple-channel3 1080p video. Real-time auto-switching between 2.4 GHz and 5.8 GHz4 enables more reliable flight near high-interference environments, while AES-256 encryption offers secure data transmission.

Enhanced flight performance

The refined airframe and propulsion system design gives you a more efficient and stable flight, even in harsh conditions

Multiple payload configurations

Configure your M300 RTK to fit your mission needs. Mount up to 3 payloads simultaneously, with a maximum payload capacity of 2.7 kg.

Smart Inspection

Live Mission Recording
Record mission actions such as aircraft movement, gimbal orientation, photo shooting, and zoom level to create sample mission files for future automated inspections.

AI Spot-Check
Automate routine inspections and capture consistent results every time. Onboard AI recognizes the subject of interest and identifies it in subsequent automated missions to ensure consistent framing. (Only compatible with H20/H20T)

Waypoints 2.0
Create up to 65,535 waypoints and set multiple actions for one or more payloads, including 3rd party ones, at each waypoint. Flightpath planning is also optimized to maximize flexibility and efficiency for your missions.

PinPoint
A quick tap marks an object in view, advanced sensor fusion algorithms immediately deliver its coordinates.

Smart Track
Identify and follow moving subjects like people, vehicles, and boats with the auto-zoom function, while continuously acquiring the subject’s dynamic location.

Location Sharing
While either PinPoint or Smart Track is enabled, the subject’s location can be projected across multiple camera views, to another remote controller, or shared through online platforms such as DJI FlightHub.

Aviation-grade situational awareness

The M300 RTK adopts a new Primary Flight Display (PFD) that integrates flight, navigation, and obstacle information to empower the pilot with exceptional situational awareness

Flight Information
Flight information such as aircraft attitude, altitude, and velocity, as well as wind speed and wind direction, are all intuitively presented.

Navigation display
Pilots can also view the live status of the aircraft’s heading, trajectory, PinPoint information, and home point projection, in a more efficient way. Visualize all nearby obstacles at once with the new obstacle map, so you can be fully informed.

Advanced dual control
Either operator can now obtain control of the aircraft or payload with a single tap. This creates new possibilities for mission strategies as well as higher flexibility during operations.

A powerful vision system you can rely on
To enhance in-flight safety and aircraft stability, dual-vision and TOF sensors appear on all six sides of the aircraft, offering a maximum detection range of up to 40m, with options to customize the aircraft’s sensing behavior via the DJI Pilot App. Even in complex operating environments, this 6 Directional Sensing and Positioning system helps keep the aircraft and the mission safe.

Professional Maintenance for your drone
The new integrated Health Management System displays the current status of all systems, notification logs, and a preliminary troubleshooting guide. Also in the system are the aircraft’s flight logs, duration, and mileage throughout its entire lifecycle, and tips on aircraft care and maintenance.

Redundancy systems for safer flights
The M300 RTK’s built-in advanced redundancy systems help keep your critical missions going even in unexpected scenarios.

Compatible Payloads:

• Zenmuse H20
• Zenmuse H20T
• Zenmuse XT2
• Zenmuse Z30
• Zenmuse X-Port
• Wingsland Z15 Spotlight
